    Product Description

    AJ-REX2-W Ajax Range Extender 2, Radio signal range extender with photo verification support

    Quick Spec:

    • Installation method: Indoors
    • Compatibility with Ajax control panels: Hub 2 (2G), Hub 2 (4G), Hub 2 Plus, Hub Hybrid (2G), Hub Hybrid (4G)
    • Compatibility with Ajax range extenders: ReX 2 does not connect to another range extenders
    • Compatibility with Ajax detectors and devices: The list of compatible device
    • Maximum connected devices (in a system with one range extender): Hub2 (2G+4G) up to 99, Hub2 Plus up to 199, Hub Hybrid (2G+4G) up to 99
    • Number of range extenders connected to the compatible hub: 5
    • Operating system: OS Malevich
    • Main power supply: 110-240 V, 50/60 Hz, 12V⎓ with 12V PSU for Hub 2/ReX 2, 6V⎓ with 6V PSU for Hub 2/Hub 2 Plus/ReX 2
    • Backup power supply: Li-Ion 2 A·h built-in backup battery, Up to 38 hours of backup battery life when Ethernet is disabled, Up to 12 hours of backup battery life when Ethernet is connected
    • Anti-sabotage: Protection against spoofing, Jamming notification, Tampering alarm
    • Dimensions: 163 × 163 × 36 mm

    Range extenders expand the boundaries of the protected area and give even more freedom to place security system devices. By connecting all or part of the devices to ReX 2, you will ensure the security and automation of a business centre, big estate, warehouse complex, or a large production facility.  5 range extenders can operate within the Ajax system to expand the radio network coverage up to 35 km. Events and alarms transmitted instantly, the first photo verification snapshots delivered to a monitoring station and users in just 10 seconds.

    Verification of alarms with snapshots

    ReX 2 works with MotionCam and MotionCam Outdoor motion detectors. When triggered, they take a series of animated pictures, helping to assess the situation at the facility. This reduces unnecessary patrol dispatches and saves the clients’ nerves.

    Guaranteed delivery of alarms and photo verifications

    To ensure reliable communications, we have equipped ReX 2 with four antennas and support for two proprietary radio protocols: Jeweller and Wings. Jeweller provides the transmission of commands, events, and alarms, while Wings ensures the transmission of visual data packages. Ajax two-way radio communication uses frames to synchronize device communication sessions, authentication to prevent spoofing, and encryption to protect against data theft.

    Radio communication through steel and concrete

    With the OS Malevich 2.13 operating system update, the ReX 2 range extender will connect to the hub not only via radio but also via Ethernet using the wire as the only or additional communication channel. A single Ajax system can cover the facility like an office centre with underground parking, or a sectional metal hangar, or a warehouse complex of several large buildings.

    Enhanced security system

    ReX 2 works as an extra intelligent control panel: it connects devices into an autonomous group and takes over control at the right time. Thanks to automatic adjustment of signal power and frame synchronization, any number of system devices can be connected to ReX 2 — the reliability of communication will not be affected by this. If, for some reason, radio communication with the hub is interrupted, ReX 2 will continue to operate via Ethernet. If a connection via Ethernet is lost, ReX 2 receives an alarm from a detector and activates a siren to draw attention to the incident and deter the burglar.

    Ready to resist intruder attacks

    ReX 2 protects from attacks at the software and hardware levels. It runs on the OS Malevich operating system, which is immune to viruses. Encrypted data transmitted by range extender. Thanks to the built-in backup battery, a sudden blackout at a facility will not be a problem.

    Evolving, not outdated

    AJ-REX2-W runs on OS Malevich, a real-time operating system developed by Ajax Systems. The OS Malevich modular architecture allows its regular updates. The operating system updates over the air. The process does not need the installer or user involvement and takes minutes when the security systems disarmed.

    Hassle-free installation

    ReX 2 connection and configuration process greatly saves the installer time. Scan a QR Code using the Ajax App to add a range extender, then assign it a name and room. Device configured in real time in app. Disable or reconfigure ReX 2 without site visits, if necessary.
